JT 8099A Epoxy Resin 100 pbw
JT 8099B Epoxy Hardener 100 pbw |
|
Liquid, hot-curing impregnation system with good electrical and mechanical end-properties.
|
| For indoor medium and high voltage application, such as Dry Current-limiting Reactor and Dry type of Transformer etc. | Applications |
| Impregnation of fiberglass and fiberglass tape together with wires. | Processing methods |
| Good impregnation on fiber and wire. Good mechanical and electrical properties (in higher temperature) | Properties |
| Hubei Jiangte Insulation Composite Guangdong Jiangte Insulation Composite Co., Ltd Add:No.219,Zhanghua Rd(N),Economic & Development Add: Xincun Industrial Zone, Changning, Boluo Zone of Qianjiang City, Hubei Province, China. Town, Huizhou City, China Tel:+86-728-6201068 Tel:+86-20-82320316 Fax:+86-728-6202066 Fax:+86-20-82315407 |
Product data(Guideline values) *
JT 8099A liquid, modified, Epoxy resin
| TYPICAL VALUES* |
| Viscosity @ 25℃, mPa.s [ISO 2555] ...................................................…....... 10,000-15,000 Density @ 25℃ , g/cm3 [ISO 1675] ...................................................................... 1.10-1.20 Shelf life@ 25℃ [in sealed container] , month………………………………………..……………..……12 |
JT 8089B Liquid, modified, anhydride curing agent
| TYPICAL VALUES* |
| Viscosity @ 25℃, mPa.s [ISO 2555] .............................................................…....... 100-500 Density @ 25℃, g/cm3 [ISO 1675] ...................................................................... 1.15 - 1.25 Vapour pressure@ 20℃, Pa [knudsen] ………………………………………..…………………..……….…<1 Shel life@ 25℃ [in sealed container] , month…………………………..………………………………….12 |
Product chemical structure diagram
Related Products
Packing & Delivery
OUR PARTER:
CLIENT FAQ:
- Thermal endurance class?
It’s Class F. Is it possible to increase the endurance class to H?
- Is their accelerator in this system?
Yes, accelerator has been prefilled into JT8098B Hardener.
- Impregnating method? Is impregnation without vacuum possible?
Yes, it’s Impregnation process. No need vacuum.
Epoxy coating powder JT105 can be a useful material for electrical insulation of wire and busbars, as well as high performance motors. Here are some features and benefits of JT105 epoxy coating powder:
Electrical Insulation: Epoxy coating powder JT105 is an excellent electrical insulator, which makes it ideal for use in electrical insulation applications. It can help to prevent electrical current from flowing through the insulation, reducing the risk of electrical breakdown or short circuits.
Corrosion Protection: Epoxy coating powder JT105 is highly resistant to corrosion, which makes it a good choice for use in harsh environments, where exposure to moisture or other corrosive substances could cause damage or corrosion.
Chemical Resistance: Epoxy coating powder JT105 is highly resistant to chemicals, which makes it a good choice for use in applications where exposure to chemicals could cause damage or corrosion.
Mechanical Protection: Epoxy coating powder JT105 can also provide mechanical protection to the wire, busbars, or motor components. The coating can help to strengthen the components, making them more resistant to bending, cracking, or breaking.
Customizable: Epoxy coating powder JT105 can be formulated to meet specific performance requirements, such as low viscosity, high filler loading, or high thermal stability. This makes it a versatile material that can be customized to meet the needs of different applications.
Overall, epoxy coating powder JT105 can be an effective and reliable material for electrical insulation of wire and busbars, as well as high performance motors. Its combination of electrical insulation, corrosion protection, chemical resistance, mechanical protection, and customization options make it a popular choice for manufacturers of electrical equipment.
